Innovations in Manganese Ore Processing Technology: Integration of Traditional and Emerging Techniques

With the rapid development of new energy industries and sustained demand from the steel sector, the strategic value of manganese resources has become increasingly prominent. As a key deoxidizer and desulfurizer in steel smelting, as well as a core raw material for lithium-manganese-iron-phosphate batteries, manganese holds an irreplaceable position in the global industrial system. According to industry analysis, with the increased penetration of manganese-based cathode materials in the new energy field, the demand for manganese in lithium batteries is expected to grow more than tenfold in the next five years, making efficient manganese ore processing technology an industry focus.

Manganese Ore Types and Mineralogical Characteristics

Manganese minerals are diverse, with mineralogical statistics indicating over 150 known manganese minerals. However, those with industrial mining value mainly include the following categories:

Oxide Manganese Ores: Including pyrolusite (MnO·MnO₂·nH₂O), psilomelane (MnO₂), manganite (MnO₂·H₂O), and wad (MnO·OH), etc. These ores primarily form in weathered deposits, with some originating from sedimentary and hydrothermal deposits. Oxide manganese ores typically contain 50-70% manganese, but often associate with elements such as iron, phosphorus, and cobalt, increasing the difficulty of mineral processing.

Carbonate Manganese Ores: Represented by rhodochrosite (MnCO₃), commonly found in metamorphosed sedimentary deposits. These ores are characterized by fine grain size, low liberation, and impurities such as sulfur and iron, making processing design particularly challenging.

According to research data from Zexin Mining's laboratory, different types of manganese ores require significantly different processing approaches, necessitating tailored beneficiation processes to maximize recovery rates.

Innovations and Applications in Manganese Ore Processing Technology

Addressing the challenges of complex composition, fine grain size, and processing difficulty of manganese minerals, the Zexin Mining technology team has conducted in-depth research and optimization of various beneficiation processes, establishing a systematic technology framework for manganese ore processing.

1. Integration of Efficient Physical Separation Technologies

Traditional physical separation methods include washing and screening, gravity separation, magnetic separation, and flotation. Zexin Mining has achieved efficient integration of these technologies through process optimization:

Optimized Washing-Screening Combined Process: Employing new high-frequency washing screens and multi-stage classification technology has improved clay removal efficiency, with experiments demonstrating a 2-5% increase in feed grade.

Enhanced Gravity Separation Technology: For coarse oxide manganese ores, a heavy medium separation system with adjustable density gradient has been developed, achieving efficient separation of 6-0mm size fraction manganese ore, with an 8% increase in recovery rate.

Magnetic Separation Technology Innovation: Development of new ultra-strong magnetic separators with magnetic field strength reaching 2000kA/m has significantly improved the recovery rate of weakly magnetic manganese minerals, achieving industrial applications with 6-12% grade improvement.

2. Advanced Combined Beneficiation Processes

For complex and difficult-to-process manganese ores, Zexin Mining has developed various combined beneficiation processes:

Gravity-Magnetic Combined Process: For manganese ores with uneven grain distribution, weak magnetic pre-selection is performed first, followed by strong magnetic separation and gravity separation of the tailings, forming a closed-circuit process with overall recovery rate increases of more than 15%.

Strong Magnetic Separation-Flotation Combined Process: For sulfur-containing manganese ores, an improved petroleum sulfonate collector system is utilized, achieving efficient desulfurization with concentrate grades consistently above 45%.

3. Chemical Processing Method Innovations

For low-grade, difficult-to-process manganese ores, Zexin Mining has developed various chemical processing technologies:

Improved Leaching Technology: Development of environmentally friendly sulfur dioxide leaching agents has significantly increased leaching efficiency while achieving solution recycling, reducing environmental impact.

Low-temperature Reduction Pyrometallurgy: Innovative development of medium-low temperature (800-1000°C) selective reduction technology has effectively separated manganese, phosphorus, and iron, reducing energy consumption while improving product purity.

Future Trends in Manganese Ore Processing Technology

With the growing demand for high-purity manganese materials in the new energy industry, manganese ore processing technology is evolving in the following directions:

1. Intelligent Processing Control Systems

Machine learning-based real-time optimization of processing parameters can automatically adjust process parameters based on changing ore properties, improving production stability.

2. Biohydrometallurgy Technology

Utilizing specific microorganisms for biological oxidation or reduction of manganese ore to achieve low-energy, low-pollution green processing.

3. Ultra-fine Grain Manganese Recovery Technology

For -0.074mm fine-grained manganese minerals, new column flotation technology and high-gradient magnetic separation technology have been developed, significantly increasing fine grain recovery rates.

Conclusion and Outlook

As a critical raw material for both the steel industry and new energy batteries, the efficient development and utilization of manganese resources are of significant strategic importance. Zexin Mining will continue to invest in processing technology research and development, continuously improving the comprehensive utilization rate and product quality of manganese resources through innovative combinations of physical and chemical processing methods, providing reliable technical support for national strategic resource security and new energy industry development.

For future processing technology development, it is recommended to conduct systematic mineralogical characteristic analysis and beneficiation research for different types of manganese ores, tailoring optimal processing solutions based on ore properties to achieve a win-win situation of resource efficiency and environmentally friendly development.
